$28,995.00

Phono Preamplifier

If you have a trade-in, request Trade-in Price.



Product Description

Over five decades ago, we invented our phono cartridge stylus, the van den Hul 1S. During these decades, we also produced phono cartridges, which are regarded as some of the best in their class and renowned worldwide. However, as a leading manufacturer of phono cartridges, it was only natural for us to create our own phono preamplifier.

This led to the launch of the original Grail in 2009. Over the years, we introduced the Grail SB (featuring balanced inputs and outputs) and the SE (including a dual mono board and balanced connectivity).

Now, we proudly present the latest addition to our lineup, the Grail SX, which serves as the successor to the Grail SE and our new flagship phono amplifier.

FEATURES

  • The highest signal to noise ratio ever.  With the newest Grail SX, you can achieve over 80dB(A) with the lowest amplification factor.
  • Developed by a class-leading phono cartridge manufacturer. Thanks to more then four decades of experience of building phono cartridges, we knew what was necessary to improve our top-notch phono preamplifier.
  • A new and redeveloped circuit board.  Thanks to the new circuit, board, the overall sound quality improved. The Grail SX made a big improvement, especially in the soundstage and the airiness.
  • Automatic loading impedance. Like the predecessor, the Grail SX also has an automatic load impedance for the cartridges, starting from 10 Ohm to 400 Ohm.
Input

Two MC inputs
MC-1 (balanced or unbalanced)
MC-2 (unbalanced only)(

One MM input (or high level output MC cartridge)
MM-1 (unbalanced only)

MM input – Amplification factor

32dB 6,2mV
40dB 2,5mV
46,5dB 1,2mV

Input impedance 47kOhm / 50pF

MC input – Amplification factor

52dB 0,62mV
60dB 0,25mV
66,5dB 0,12mV

Input impedance from 10 Ohm till 400 Ohm

Max. undistorted output voltage (<1%)

15Vss for MM signal path, 8,5Vss for MC signal path

Output impedance

330 Ohms (real resistive), 600 Ohms at balanced out

Input sensivity values

(given for 250mV RMS resp. 0,707Vss output level on amplifier output)

Signal to noise

Over 80dB(A) with the lowest amplification factor.

Input impedance

Autom. matching in milliseconds from appr. 10 Ohms up to 400 Ohms

Temperature operating range

from 15deg. Celsius up to 35deg. Celsius room temperature. No condensing on item allowed. Use only in dry rooms

Size (W x H x L, incl. feet)

475 x 95 x 335mm

Weight

13,5KG (appr.30lbs) without the ext. power supply

Mains power

Available with 115/120Volts or 230Volts, 50/60Hz.

Available colons

Matte silver alui

tracking anglelogo

A Holy Upgraded The Grail SX

AN UPDATED CIRCUIT AND A MORE CONVENIENT OPERATING SYSTEM

Many Grails ago, in 2009, van den Hul introduced its original “The Grail” transimpedance-based MC/MM phono preamplifier. I reviewed it in 2018 when it cost $7950. Yes, it’s pretentious to name anything, but especially an audio product, “The Grail” but at least it wasn’t called “The Holy Grail” and it wasn’t packed in a cup and didn’t promise mystical healing powers. But it surely did deliver the promised outstanding sonic performance and it’s still in production, now costing $8995..

That original “The Grail”, featuring gracefully sculpted wooden side “cheeks” and a white “pebbly finished” aluminum main chassis plus “basic black” outboard power supply, offers a single-ended current amplification-based MC input and a single-ended voltage based MM input as well as capacitor-free inductor-resistor based RIAA filtration among a host of useful circuit attributes.

A seriously upgraded version, The Grail SE+ ($23,995), which I reviewed in 2020, included dual mono circuitry, improved power supplies, and added a choice of balanced XLR or single-ended RCA in one of its two current-based MC inputs and balanced-only in the second MC input plus a single-ended moving magnet voltage amplification-based input. van den Hul also sells a “The Grail SE” ($19,995) dual-mono version and “The Grail SB” ($16,995) fully balanced edition.

Read Full Article Here

Brand

van den Hul

Precision handmade masterpieces. All van den Hul cartridges are personally hand built and tuned by Dutch master cartridge designer A.J. van den Hul. They are packed in attractive boxes and accompanied by all the cartridges specifications and Mr. van den Hul’s personal signature. Overture is a proud dealer of van den Hul products, selling customers the best moving coil phono cartridges and phono preamplifiers from van den Hul. Interested in purchasing a new van den Hul phono cartridge or phono preamplifier? You can trade-in any phono cartridge or phono preamplifier towards a van den Hul product by filling out our Trade-In Form.
