Product Description
New Features in the Parasound P 6 Preamplifier
- ESS Sabre32 Reference DAC replaces the original Burr-Brown DAC
- USB input is now capable of DSD; 384kHz/32-bit PCM (up from 96Khz/24-bit)
- Burr Brown analog resistor ladder volume control
- Dimmable front panel volume display
- Upgraded USB receiver with “plug and play” operation with Windows 10
- An additional optical input (2 total)
- Ball bearing supported solid aluminum volume knob
- Programable default turn on volume setting
- Favorite volume memory with remote control button in the Parasound P 6 Preamplifier
- Increased phono stage gain for lower output cartridges
- Improved Left/Right channel separation and balance tracking
- Sand blasted metal end caps replace plastic end caps on the P 5
- Updated cosmetics with subtle gold highlights
Parasound P 6 Preamplifier and DAC Features
- Parasound P 6 has ESS Sabre32 Reference DAC (ES9018K2M)
- Asynchronous USB 2.0 supports PCM up to 384kHz/32-bit
- USB input decodes Native DSD64, DSD128, DSD256 and DoP DSD
- Coax and optical inputs accept PCM up to 192kHz/24-bit
- Analog bass management with high & low pass crossovers
- Home theater bypass input for surround sound integration
- Front panel subwoofer level control
- Dedicated high current headphone amplifier (TI TPA6120)
- Phono input for MM, MC and MI with 100 Ω or 47k Ω load
- Front panel Aux input with automatic +12 dB gain stage
- 5 pairs RCA line level Analog inputs
- 1 pair XLR balanced Analog input
- Balanced XLR and RCA left and right preamp outputs
- 1 balanced XLR and 2 RCA subwoofer outputs
- Bass & treble controls with relay bypass from remote or front panel
- Rear panel IR input and IR loop output jacks
- 12 Volt trigger output
- Back-lit remote control with discrete buttons
- 0.5w standby power consumption meets Energy Star; EU specs
